سوئیچ شبکه KP-۲۴۰۸H۴SMU
| 32 PORT Full Gigabit Layer 2 PoE Switch 24 Gigabit RJ45 PoE Port (Up To 90 Watt Per Port) 4 Gigabit RJ45 Uplink Port 4 Gigabit SFP Uplink Port 600 Watt 56Gb Internal Bandwidth Realtek Processor PoE Distance up to 120m Metal Case |
توضیحات
قابلیت های هوشمند:
|
| سایر برتری ها :
سخت افزار منحصر بفرد جهت پایداری در تمام شرایط |
شرایط گارانتی :
|
Interface |
|
| Total Port | 32 Ports |
| POE Output (Max) | 600 Watt |
| POE Port Control | Realtek 8238B/8239B |
| Fast RJ45 POE Port | N/A |
| Gigabit RJ45 POE Port | 24 Port Port 1~4 BT (Up to 90W) – Port 5~24 AT (Up to 30W) |
| Fast RJ45 Uplink Port | N/A |
| Gigabit RJ45 Uplink Port | 4 |
| Gigabit SFP Uplink Port | 4 |
| Combo Uplink Port | Yes(Port25~Port32) |
| Power Transmit RJ45 Port Fast RJ45 Uplink Port | N/A |
Network Performance |
|
| Standard | IEEE802.3x, IEEE802.3u, IEEE802.3az, IEEE802.3ab, IEEE802.3af, IEEE802.3at(Up to 30Watt), IEEE802.3bt |
| Protocols | CSMA/CD |
| Router | N/A |
| Speed | Ethernet 10Mbps (half duplex), 20Mbps (full duplex); 10BASE-T: 14,880bps/port Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX:14,8800bps/port Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full duplex); 1000BASE-TX: 1488000bps/port |
| Cabling | 10Base-TX: Cat 5 or above (250m) POE=250M 100Base-TX:Cat 6 UTP(120m) POE=250M 1000Base-TX: Cat 6 UTP or above (100m) POE=250M |
| Bandwidth | 56Gb Internal Bandwidth |
| MAC Table | 64Kb |
| Auto MDI-MDIX | Yes All Ports |
| Console | Yes – Web & RS232 Layer2 Management (Telnet / SSH/ CLI) |
| Transfer Pattern | Store & Forward |
| Feature | |
| Security | Port Security, Access IP List, SSH & HTTPS Login, IEE 802.1 X MAB (MAC Authentication Bypass)/Radius Server Authentication |
| Hardware | |
| Processor Type | Realtek |
| LED Panel | POE Activity, Data Activity, Power Activity |
| Main Board | Double Layer |
| Case | Metal Case |
| Mounting | Rackmount |
PD’S |
|
| IP Camera | Yes |
| IP Phone | Yes |
| (+)2/1,(-)6/3 | Yes |
| General | |
| Protection Rating | IP51 |
| Web Language | English |
| Dimension | 440*295*45 mm |
| Weight | 2.65 kg |
| Storage Temp | -20°C ~ +60°C / 10% ~ 90% RH |
| Operation Temp | -15°C ~ +50°C / 10% ~ 90% RH |
| Radiation Electromagnetic | EN55016 |
| Power Supply | |
| Power | 200~240V AC, 50~60Hz |
| Redundant | N/A |
| LED Power | Yes |
| Power Cable | Available |
Guarantee |
|
| Product Guarantee | 3 Years Platinum Guarantee |
| MTBF | 100K hrs min. MIL-HDBK-217F (25°) |
